EKF52315 UL标准电缆屏蔽型 UL2464 Shielded Computer Cable

Applications:

As measuring, monitoring and control cable, it is suitable for the places of machine tool manufacturing, complete equipment installation engineering, power station, refrigeratory equipment, OA equipment, data processing system and heating and air-condition system.

Properties:

Heat resistance, good insulation property, excellent chemical performance, electromagnetic wave resistance

Standards: UL 758

Structure:

Conductor: fine strands of tinned copper wire, exellent corrosion resistance.

Insulation: special PVC

Colour: acc. to UL 758

Earth wire: bare copper

Shield: bare or tinned copper shielded

Sheath: 80℃ heat-resistant flame-resistant PVC, pass VW-1 flame testing

Colour: black (RAL9005)  green (RAL6018)

       Orange(RAL2003) purple(RAL4001)

Or refer to customer’s requirement.

Technical data:

Rated voltage: 300V

Test voltage: 2000V

Temperature range: Fixed installation: -40℃­--+80℃

                Flexing installation: -10℃--+80℃

The minimum bending radius: Fixed installation: 4×external diameter

Flexing installation: 15×external diameter

应用范围:

作为测量、监测和控制电缆适合用在机床制造、成套设备安装工程、电站、暖气和空调系统、冷冻设备、办公自动设备、以及数据处理系统等场合。

产品特性：

耐热阻燃，绝缘性能优异，化学性能稳定，由于采用了新性的铝箔麦拉加铜网编织双层屏蔽，有效抵抗电磁波干扰。

应用标准：UL758

电缆结构：

导体：多股精绞镀锡铜丝，抗腐蚀性强

绝缘：特殊硬质耐热阻燃PVC绝缘

颜色：符合UL758

内屏蔽：铝箔麦拉包裹屏蔽。

排流线：（可选）与导体同规格排流效果，方便了线束屏蔽加工。

编织：裸铜丝或镀锡铜丝编织屏蔽（可选）。

护套：混合80度耐热阻燃PVC护套，通过VW-1 阻燃试验

绿色（RAL6018）  黑色（RAL9005）

橙色（RAL2003）  紫色（RAL4001）

亦可按客户要求定制生产。

详细参数：

额定电压：300V

测试电压：2000V

使用温度范围：固定安装：-40℃—+80℃
